3M™ Thinsulate™ Van Insulation Kit for Mercedes Sprinter (2007+, Pre-Cut)

Name: 3M™ Thinsulate™ Van Insulation Kit for Mercedes Sprinter (2007+, Pre-Cut)
Brand: Campervan HQ
SKU: S-144H-FV-AU6002-5-KIT
Price: 632.33 USD
Availability: InStock

$632.33 USD

SOLD OUT

Sprinter Van Model: High-Roof Mercedes Sprinter 144"WB Cargo Van High-Roof Mercedes Sprinter 144"WB Cargo Van High-Roof Mercedes Sprinter 170"WB Cargo Van High-Roof Mercedes Sprinter 170" EXT Cargo Van Low-Roof Mercedes Sprinter 144"WB Cargo Van

Quantity

Meet the proven way to quiet and stabilize temps in your Sprinter build.

Free shipping to the lower 48 US states. Please allow 1–2 weeks before shipping.

This pre-cut 3M™ Thinsulate™ AU6002 kit is CNC-cut to the main wall, ceiling, and door cavities of 2007+ Mercedes Sprinter cargo vans, covering 144" WB (Low & High Roof), 170" WB High Roof, and 170" Extended High Roof, so you can install cleanly without hours of templating. The hydrophobic non-woven blends polyester and ultra-fine polypropylene fibers to deliver excellent acoustic absorption and reliable thermal performance; lightweight, compressible, and conformable for a professional finish behind panels.

Why builders choose this kit

Drop-in, pre-cut pieces save serious build time and mess.
AU6002 is engineered for noise reduction.
Hydrophobic fibers resist moisture, mold, and mildew; no extra vapor barrier needed in typical use.
Meets FMVSS 302 flammability requirements for automotive interiors.

What’s included

Pre-cut AU6002 panels for cargo-area walls, ceiling, and doors
Placement diagram for piece locations
Coverage designed for open cavities in the cargo area

What’s not included

Cab area and vehicle floor
Material to stuff between beams or fully/partially covered cavities
Window surrounds beyond the main open cavity pieces (you may have extras if you have windows)

Video: 3M™ Thinsulate™ Van Insulation Kit for Mercedes Sprinter

3M™ Thinsulate™ AU6002 — Key Specs

Attribute	Spec	Notes
Material	3M™ Thinsulate™ Acoustic Insulation AU6002	Double black, double-embossed scrim
Roll Width	60 in (1524 mm)	Standard AU6002 width
Thickness	~44 mm	Nominal, uncompressed
Density	~16.1 kg/m³	Typical for AU6002
Thermal Resistance	Approx. R-5.45 per inch (RSI ≈ 0.96)	Commonly referenced in van applications
Acoustic Behavior	High absorption, mid–high frequencies	Engineered for vehicle sound control
Fire Resistance	Meets FMVSS 302	Automotive flammability standard
Moisture Behavior	Hydrophobic fibers	Resists moisture, mold, mildew
Install Method	Adhere panels inside cavities	Pre-cut per cavity; diagram included
Coverage	Walls, ceiling, doors (cargo)	Cab and floor not included

Fitment & Variants

144" WB Low Roof (2007+)
144" WB High Roof (2007+)
170" WB High Roof (2007+)
170" Extended High Roof (2007+)

Coverage targets the main open cavities in the cargo area (walls, ceiling, doors).

FAQ (Frequently Asked Questions) click to expand

1.Will this fit my 2007+ Sprinter?

Yes. The kit is cut for 2007+ Mercedes Sprinter cargo vans covering 144" WB (Low & High Roof), 170" WB High Roof, and 170" Extended High Roof.

2.Does it include the cab or the floor?

No. Coverage is for cargo-area walls, ceiling, and doors only. Cab and floor are not included.

3.Is a vapor barrier required?

3M™ Thinsulate™ fibers are hydrophobic and resist moisture, mold, and mildew in typical van applications. Most builders do not add a separate barrier behind panels. Follow your build approach and local codes.

4.How does AU6002 help with road noise?

AU6002 is an automotive acoustic insulator with high absorption, especially in the mid-to-high frequencies common to road and wind noise.

5.What about fire safety?

AU6002 meets the FMVSS 302 interior flammability standard commonly used for vehicle components.

Get a CAD-Verified Roof Layout

We understand that every van setup is unique. That's why we offer CAD-verified roof layouts for customers who have purchased or plan to purchase an Orion roof rack - so you can maximize space and fit exactly what you need, where you need it. Request a layout here ›
