Victron MultiPlus 120V Inverter Charger

Name: Victron MultiPlus 120V Inverter Charger
Brand: Victron Energy
SKU: ART-PMP121500100-VIC
Price: 261.8 USD
Availability: InStock

$261.80 USD

SOLD OUT

Voltage: 12V 12V 24V 48V

Continuous Output Power: 500VA 500VA 800VA 1200VA 2000VA 3000VA

UL Certification: UL Certified UL Certified

Quantity

Overview

The Victron Energy MultiPlus is a combined inverter and battery charger for 120V AC systems. It integrates a true sine wave inverter, adaptive charging, and a high speed AC transfer switch in one enclosure. Select the voltage, continuous output power, and UL status that matches your build.

Key Features

True sine wave inverter
Adaptive charge technology
PowerAssist and PowerControl
High speed AC transfer switching for seamless source changes
VE.Bus communication port for parallel operation, remote monitoring, and system integration

Important Info

Match the MultiPlus DC voltage to your battery bank, and confirm UL requirements for your installation before ordering.

Variant Specs

The specs below summarize key electrical characteristics for the exact variants listed on this product page. For full details, refer to the manufacturer's documentation for the specific part number.

Technical Specs

Spec	Details
AC output	120VAC ± 2%, 60Hz ± 0.1%
AC input range (charger)	95 to 140VAC
System integration	VE.Bus communication port for parallel and three phase operation, remote monitoring, and system integration

Variant Summary

Spec	Details
12V 500VA, PMP121500100	430W at 25°C, 20A charger, 16A transfer switch, DC input 9.5 to 17V
12V 800VA, PMP121800100	700W at 25°C, 35A charger, 16A transfer switch, DC input 9.5 to 17V
12V 1200VA, PMP122120100	1000W at 25°C, 50A charger, 16A transfer switch, DC input 9.5 to 17V
12V 2000VA, PMP122200102	1600W at 25°C, 80A charger, 50A transfer switch, DC input 9.5 to 17V, peak power 4000W
24V 2000VA, PMP242200102	1600W at 25°C, 50A charger, 50A transfer switch, DC input 19 to 33V, peak power 4000W
24V 2000VA, PMP242200100	1600W at 25°C, 50A charger, 50A transfer switch, DC input 19 to 33V, peak power 4000W
48V 2000VA, PMP482200100	1600W at 25°C, 25A charger, 50A transfer switch, DC input 38 to 66V, peak power 4000W
12V 3000VA, PMP122301102	2400W at 25°C, 120A charger, 50A transfer switch, DC input 9.5 to 17V, peak power 6000W
24V 3000VA, PMP242301102	2400W at 25°C, 70A charger, 50A transfer switch, DC input 19 to 33V, peak power 6000W

Frequently Asked Questions (click to expand)

1. What is the Victron MultiPlus?

MultiPlus is a combined inverter and battery charger designed to provide 120V AC power from a battery bank, and to charge the batteries when shore power or a generator is available.

2. Which voltage should I choose, 12V, 24V, or 48V?

Choose the MultiPlus that matches your battery bank voltage. For example, a 24V battery bank requires a 24V MultiPlus.

3. How do I choose the right continuous output power rating?

Select a rating that covers your expected continuous loads and allows headroom for starting surges. If you share a load list, the right size can be estimated.

4. What does the transfer switch rating mean?

The transfer switch rating indicates the maximum AC current that can pass through from an external AC source when available. Ratings vary by model, for example 16A on 500VA to 1200VA models and 50A on 2000VA and 3000VA models.

5. What is PowerAssist?

PowerAssist allows the MultiPlus to supplement a limited external AC source with inverter power from the batteries when loads exceed the available shore or generator capacity.

6. What does UL Certified vs Not UL Certified mean on this listing?

This store offers both UL and non UL variants for select models. If you need inspection compliance, confirm the required listing for your jurisdiction and select the matching variant.

7. What is included in the box?

Included items are not confirmed from the provided sources. This listing assumes the main MultiPlus unit only unless you provide an official packing list.

8. Can I parallel multiple units or build split phase?

MultiPlus units support parallel operation. Certain configurations can be used for split phase setups when stacked, and system design should follow manufacturer documentation.
